Description
Features
• Enhanced EMI immunity
• Ruggedized clip fixing
• Improved wear-out and decontamination properties
• Increased buzzer volume
• Compact and lightweight
• Standard AAA alkaline battery for 1800 h of operation
• Solid-state detector
• Digital display for integrated dose or alternatively dose rate
• User selectable alarm levels for both dose and dose rate
Radiation detected:
– gamma and X-rays
Detectors:
– energy compensated Si-Diode
Measurement range:
– dose: 1 μSv – 9.99 Sv or 0.1 mrem – 999 rem
– dose rate: 5 μSv/h – 3 Sv/h or 0,5 mrem/h – 300 rem/h
Calibration accuracy:
– better than ±5% (Cs-137, 662 keV at 2 mSv/h), Hp(10)
Energy response:
– Hp(10), 60 keV – 3 MeV, better than ±25%, up to 6
MeV, better than ±35%
Dose rate linearity:
– better than ±15%, up to 3 Sv/h (300rem/h)
– better than ±10% for 0.005 mSv/h – 1 Sv/h
(1mrem/h-100 rem/h
Audible alarms:
– eight separate alarms, sound level typically better
than 85 dBA at 30 cm
– integrated dose
– dose rate
– dose overflow
– dose rate over flow at 3 Sv/h or 300 rem/h
– low battery 1 and 2
– defect
Alarm thresholds*
Dimensions: 78 x 67 x 22 mm (3.1 x 2.6 x 0.8 in)
Weight: 80 g ( 2.8 oz) including battery
