RDS 30 MALAYSIA

The RDS-30 is a Digital Handheld Dose Rate Meter designed for a wide range of applications involving a possibility for abnormal radiation levels. Compact, lightweight, waterproof, its performance and its friendly user interface make the RDS-30 perfectly suited to radiation survey in field conditions, in the nuclear industry, and for protection against radiological hazards by personnel, who may be exposed to gamma and or X-ray radiation in their work. RDS-30 is microprocessor controlled. The user interface consists of one push-button and an easy-to-use menu structure that displays information on the LCD of the meter. The six-digit display shows the dose rate and various messages. Different alarm situations are indicated by a combination of audio-visual effects on the LCD and a buzzer (dose rate, dose, low battery, defect, dose rate overflow).

Category:

Description

Specification

Radiation detected: gamma and X-ray from 48 keV to 3 MeV

Detector: energy compensated GM tube compliant to H*(10)

Dose rate measurement range: from 0.01 μSv/h to 100 mSv/h or from 1 μrem/h to 10 rem/h

Dose rate linearity: ± 10 % ±1 digit within the range of 0.1 μSv/h to 100 mSv/h or 10 μrem/h to 10 rem/h

Backlit display with six large digits

Display in either μSv/h or in mrem/h (configurable per request)

Built-in self-diagnostics for GM-tube operation, high voltage, and battery capacity

Energy response: ± 30 % over the range of 48 keV – 3 MeV

Dose measurement range: from 0.01 μSv to 1 Sv or from 1 μrem to 100 rem

Case: rugged plastic, easily de-contaminable

Dimensions: 78 x 126 x 32 mm

Weight:

– 170 g without batteries

– 220 g with batteries
